USB GPS Receiver JFT – AV01

Use UIDAI approved USB GPS receiver JFT-AV01 which is manufactured by Jellyfish Telecommunication Private Limited. This USB GPS receiver is very cost effective, professional, easy to use, robust in design and has very low power consumption. This receiver is compatible with Windows operating system. This receiver uses both GPS + GLONASS L1 band receivers so positioning is more accurate.

Make : Jellyfish Telecommunication Pvt. Ltd.
Made in India
Model no. JFT-AV01

Technical Specifications

GPS chipset: Chipset Media Tek
Protocols: NMEA 0183, MEA0183 V3.0 protocol and supports commands GGA,GSA,GSV,RMC,VTG,GLL v2.2
Frequency: GPS L1 Band Receiver (1575.42MHz)
GLONASS L1 Band Receiver(1601.71MHz)
C/A Code: 1.023 MHz
Channels: 33 (Tracking), 99 (Acquisition)
Temperature: -40⁰C to 85⁰C
Humidity: Upto 95% non-condensing
Sensitivity: -161dBm to -167dBm
Accuracy:
Horizontal Position Accuracy Autonomous <2.5m CEP
Velocity Accuracy Without Aid <0.1m/s
Acceleration Accuracy Without Aid 0.1m/s².
Anti-jamming: Multi-tone active interference canceler.

Acquisition Rate:

Hot Start: <2s
Warm Start: <32s
Cold Start: <32s
Reacquisition: <1s
Update Rate: 1Hz
Baud Rate: 9600 bps

Dynamic Performance:

Maximum Altitude: Max.18000m
Maximum Velocity: Max.515m/s
Maximum Acceleration: 4G

Compatible with:

Windows operating system

Physical Attributes:

Diameter : 55mm
Height : 25mm
Cable Length : 2m

Electrical Characteristics:

Voltage: 5.0 V USB
Current: 50mA (typical)
